Schneider Reactor

Name: Schneider Reactor
SKU: LVR07150A40T

Brand:

Schneider

Series:

Reactance:

0.07

Number Of Phases:

Three-phase

Rated Current:

26A

Rated Voltage:

400VAC

Model:

Reactor 15KVAR/190HZ/7%

Order Number:

LVR07150A40T

Description:

Schneider Reactor Reactor 15KVAR/190HZ/7%, rated voltage 400VAC, rated current 26A, reactance 0.07, three-phase

WhatsApp Inquire Now

Product parameters
Series Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Schneider
Series：	DR
Reactance：	0.07
Number Of Phases：	Three-phase
Rated Current：	26A
Rated Voltage：	400VAC

Products with the same attribute : 0

Show details

Series Overview

Function of DR Tuning Reactor

Connected in series with a tuning capacitor to form a tuning - type reactive power compensation device
Protect capacitors and prevent harmonic amplification
Absorb part of the harmonic current and play a certain filtering role
The selection of DR tuning reactors should be based on the harmonic spectrum of the system
DR tuning reactors must be used in series with tuning capacitors

Operating Conditions

For indoor use
Storage temperature: - 40°C, + 60°C
Operating relative humidity: 20 - 80%
Salt spray resistance: 250 hours
Operating temperature:
- Altitude ≤ 1000m: Min = 0°C, Max = 55°C, maximum annual average temperature = 40°C, 24 - hour average temperature = 50°C
- Altitude ≤ 2000m: Min = 0°C, Max = 50°C, maximum annual average temperature = 35°C, 24 - hour average temperature = 45°C

Installation Method

Must be installed vertically
Vertical installation is conducive to heat dissipation
