KDF9H Sanhua Solenoid Valve

Name: KDF9H Sanhua Solenoid Valve
SKU: Sanhua-KDF9H-4

Brand:

Sanhua

Min. OPD:

7 kPa

Max. OPD[DC]:

2.8 MPa

Max. OPD[AC]:

3.1 MPa

Max. Working Pressure:

4.5 MPa

Actuation:

Pilot (piston operated)

Normal Position:

Current:

Kv:

1.3 m³/h

Series:

KDF

Model:

KDF9H

Order Number:

Sanhua-KDF9H-4

Description:

KDF9H Sanhua Solenoid Valve, 1.3 m³/h, maximum operating pressure: 4.5 MPa, maximum operating differential pressure [AC]: 3.1 MPa, maximum operating differential pressure [DC]: 2.8 MPa, minimum operating differential pressure: 7 kPa

WhatsApp Inquire Now

Product parameters
Product Overview

Product parameters

Product attributes	Attribute value	Filter product attributes
Brand：	Sanhua
Min. OPD：	7 kPa
Max. OPD[DC]：	2.8 MPa
Max. OPD[AC]：	3.1 MPa
Max. Working Pressure：	4.5 MPa
Actuation：	Pilot (piston operated)
Normal Position：	NC
Current：	AC
Kv：	1.3 m³/h
Series：	KDF

Products with the same attribute : 0

Show details

Product Overview

KDF series Solenoid Valves are piston type pilot operated Solenoid Valves, mainly used in refrigerant control of various devices such as refrigeration, air conditioning and heat pumps. The maximum admitted refrigerant temperature (equal to +140°C) permits to install KDF valves in gas injection or hot gas bypass lines such as in the compressor discharge line.

FEATURES

• VALVE BODY WITH COMPACT DESIGN, EASY TO MANAGE AND INSTALL

• DETACHABLE DESIGN, EASY FOR CLEANING AND MAINTENANCE

• LEAD WIRE AND DIN CONNECTION TYPE COILS ARE AVAILABLE

GENERAL SPECIFICATIONS

• Applicable for all common HCFC, HFC refrigerants (Used for pure refrigerant oil circuit pls contact SANHUA)

• Medium temperature TS min./max.: -40°C/+140°C

• Ambient temperature min./max.: -30°C /+50°C

• Relative humidity: 0 to 95%RH

• Max. operating pressure PS: 4.2MPa
